Long Distance Transmission RG213 Coaxial Cable With PE Insulation And Copper Conductor

Name: Long Distance Transmission RG213 Coaxial Cable With PE Insulation And Copper Conductor
Brand: SIHUAN
Price: 1 USD

Long Distance Transmission RG213 Coaxial Cable With PE Insulation And Copper Conductor Manufactures

Place of Origin : Zhejiang, China

Brand Name : SIHUAN

Model Number : RG213

MOQ : 5 kilometers

Price : Negotiable

Conductor Material : Copper

Insulation Material : PE

Jacket : PVC

Number of Conductors : 1

Application : COMMUNICATION, Telecommunications

coaxial cable rg213 : coaxial cable RG213

Type : Coaxial

lead time : 30days

origin : china

Contact Now

coaxial cable RG213

IMPEDANCE : 50ohms

INNER CONDUCTOR DIAMETER : 7 STRANDS 0.0296"

INNER CONDUCTOR MATERIAL : BARE COPPER

DIELECTRIC DIAMETER : 0.285"

DIELECTRIC MATERIAL : SOLID PE

NUMBER OF SHIELDS: 1

SHIELD MATERIAL : BARE COPPER :

OUT DIAMETER :0.405"

JACKET : PVC

NOMINAL CAPACITANCE (pf/ft) : 30.8

OPERATING TEMPERATURE: -40° to 80 °

MAX OPERATING VOLTAGE (VOLTS RMS) : 5000

NOMINAL ATTENUATION (PER 100FEET)

10 MHZ .66dB

100MHZ 2.20dB

1GHZ 9.0dB

5GHZ 28.00dB

10GHZ 47.00dB

MAXIMUM POWER HANDLING (AVERAGE POWER IN WATTS)

10MHZ 3700

100MHZ 850

1G GHZ 190

5 GHZ 65

10 GHZ 37

Long Distance Transmission RG213 Coaxial Cable With PE Insulation And Copper Conductor

Product Tags:

PE Insulation rg213 coaxial cable

Copper Conductor rg213 coaxial cable

Long Distance Transmission rg213 cable
